How to Enable Split VPN in Windows & Mac?

Although many people believe that these technologies are exclusively for security, they offer numerous additional advantages. Individuals can, for instance, avoid geoblocking technology, which restricts users' access to particular websites and apps based on their locations. While some people use VPNs for security, others may use them to improve their access speed.

Although the connection may not get slow while utilizing a personal one, the efficiency may be affected due to the workload in corporates where various endpoints utilize the same tunnel for access. Fortunately, there is a technique to control how your VPN creates tunnels. An advanced setting named Split Tunneling permits you to regulate which endpoints utilize more secure tunnels and which utilize faster ones. In this post, we will define VPN split tunneling and show you how to utilize it in various operating systems.

What is VPN Split Tunneling?

VPN split tunneling is a sophisticated attribute that helps companies and individuals to separate the tunnels your endpoints and programs utilize to enhance efficiency. Thanks to this method, corporates can reduce the workload of a tunnel hence increasing others’ speed. Even though preventing these capabilities to use these encrypted tunnels may seem like compromising security, when adopted properly, split tunneling may bring significant benefits.

With this method, individuals and companies can acquire enhanced control over their programs, services, and endpoints. Also, this process permits them to solve small but frustrating problems like printer errors due to VPN usage. In short, this feature provides users with enhanced speed and control. However, you should keep in mind that with this technique, the program does not provide all endpoints with encrypted access. To put it another way, this method chooses performance over safety but how?

How Does It Increase Efficiency?

To understand how this trait works, one should first comprehend the way a VPN functions. Essentially, a VPN masks individuals’ online actions by establishing encrypted tunnels. This gives the user comprehensive confidentiality and protection. Once a VPN is implemented, Internet Service Providers and other third parties are no longer able to monitor the data transmitted or acquirer or the sites browsed online. As a consequence, the VPN host you pick conceals all the personal info you share via individual online actions.

VPN Split Tunneling, on the other hand, permits individuals to regulate how endpoints together with programs may utilize these encrypted tunnels and which may not. And this delivers enhanced control of how your endpoints and software utilize the tunnels. Thanks to such enhanced control, the workload on the related servers is kept to a minimum while enhancing the efficiency of devices that need it more. Also, preventing some apps to use these capabilities does not necessarily mean reduced safety. Rather, individuals may disable it for certain endpoints together with the programs that would not compromise the network security while increasing efficiency.

Instructions to Activate Split Tunneling

To activate Split Tunneling VPN contingent on whether you have Windows or Mac, a variety of steps should be followed. Yet, the first step is to check if the current VPN has this option. Furthermore, activating it is generally an easy task. First, let’s start with the instruction for activation in Windows OS:

Instructions for Windows OS

Start by right-clicking on the Windows icon and browsing Network Connections. After that, open the Change Adapter Options menu then browse VPN connections. Navigate to Properties, and choose TCP/IPv4 in the Networking tab. Open the main page, choose Advanced options, then deactivate the 'Use default gateway on remote network'. Restart the tunneled link for modifications to function properly.

Here is another practice that is relatively simple but for advanced users. Start by following the first step above but select Windows PowerShell (Admin). You can enter  'Get-VPNconnection' command to view the titles of all programs that utilize the service.

Enter the command below to activate it on the program you prefer.

'Set-VPNconnection -Name (VPN Name) - SplitTunnelung $True'.

Change the title with the current title and press Enter. To check if the feature works, type 'Get-VPNConnection Command' again.

For deactivating the function, use: “Set-VPNconnection -name YourVPNconnection -SplitTunneling $false”.

Instructions for Mac Os

To manually activate the trait on Mac Operating System, Navigate to Preferences. After that open the Network tab and browse the VPN connection (located in the left sidebar). Navigate to Advanced settings then Options. box should be unchecked. Confirm the modifications and activate them.

Once activated, browse the following menus respectively: Application > Utilities > Terminal. Type the “ifconfig” command with all lowercase in there. Keep a record of the VPN's interface which often is ppp0.  Log in as root. To execute the task, write “sudo su” into the terminal and provide your Mac login credentials. Lastly, change [DESTINATION] with the subnet you wish to browse via the VPN, and [VPN INTERFACE] with the code you recorded previously.

To deactivate disconnect from the VPN, write “route delete [DESTINATION]”

Instructions for Built-in Features

If the instructions mentioned above seem complex, it may be more suitable for you to implement a program that comes with a built-in option. Since most providers use similar interfaces, you can activate it by

Opening the Settings.Activating it to direct the configurations regarding the URL or service.Choosing preferred URLs or sites to browse via VPN together with those you prefer to view straight through the open network.Finish the configurationsMonitor the tunnel’s connectivity by clicking on a URL.

Benefits of Split-Tunneling

This sophisticated feature may bring significant benefits to users. Although it may be more beneficial for companies with remote employees, it also can be advantageous for individuals. However, when employing this feature, you may encounter various security risks. Yet, when one manages to implement it right, it can reduce the possibility of dangers.

Also, in most circumstances, safeguarding all the data sent and received is unneeded. Merely maintaining privacy on only necessary actions can increase your online experience without jeopardizing safety. With this advanced option, individuals can enjoy the advantages of enhanced efficiency and increased control over their apps. Furthermore, that spares individuals a significant amount of bandwidth.

Final Words

This advanced VPN feature may come in handy for most since it significantly increases the access efficiency of the user while considerably maintaining network security. However, if the main concern is safety, you may choose to remain with the current configurations. Yet, if the endpoints have some apps rising the workload of the tunnels unnecessarily, consider activating the option to enhance the efficiency considerably.

Furthermore, if you modify the privacy preferences of applications that would not use VPN capabilities, any danger or risk as a result of using this attribute can be reduced drastically. This eliminates the software's main major disadvantage.
